| 參數 Specivfications | 單位Unit | 技術指標 Technique data |
| 額定載荷 | Rated capacity | t | 0.05、0.5、1、10...20 |
| 輸出靈敏度 | Output sensitivity | mV/V | 2.0±0.002 |
| 非線性 | Non-linearity | %F.S | ≤±0.03 |
| 滯后 | Hystersis | %F.S | ≤±0.03 |
| 重復性 | Repeatability | %F.S | ≤±0.03 |
| 蠕變 | creep | %F.S/30min | ±0.03 |
| 溫度靈敏度漂移 | Temperature sensitivity drift | %F.S/10°C | ±0.03 |
| 零點溫度漂移 | Zero point temperature drift | %F.S/10°C | ±0.03 |
| 零點輸出 | Zero output | %F.S | <±1 |
| 輸入阻抗 | Input resistance | Ω | 380±10 |
| 輸出阻抗 | Output resistance | Ω | 350±3 |
| 絕緣阻抗 | Insulation resistance | MΩ | ≥5000 |
| 工作溫度范圍 | Operating temperature | °C | -20~60 |
| 安全過載 | Safe overload | %F.S | 150 |
| 極限過載 | Ultimate overload | %F.S | 30o |
| 推薦工作電壓 | Recommended excitation voltage | VDc | 5~12 |
| 最大工作電壓 | Maximum excitation voltage | VDc | 15 |
| 材質 | material | 合金鋼Alloy steel |
| 防護等級 | lP protection | IP65 |
| 備注 | Note | 可提供標準變送器模塊NS-A002/A003，輸出信號為4~20mA，0~5V,
0~10V，Profibus，Modbus，CANOpen RS485可選 |
